EN User manual PT-BR Manual do usuário
English
1 Your electric pressure cooker
Congratulations on your purchase, and welcome to Philips!
To fully benet from the support that Philips oers,
register your product at www.Philips.com/welcome.
2 What’s in the box (fig. 1)
Electric pressure cooker main unit
Multi-usage spoon User manual
Measuring cup Recipe booklet
Safety leaet Power cord
Warranty card
3 Overview
Product overview (g. 2)
a
Safety valve
h
Power socket
b
Lid handle
i
Heating element
c
Top lid
j
Locking pin
d
Sealing ring
k
Floater
e
Water level indication
l
Floating valve
f
Inner pot
m
Pressure regulator
g
Control Panel
Controls overview (g. 3)
n
Pressurize indicator
v
Preset timer button
o
Heating indicator
w
Warm/O button
p
Power indicator
x
Manual button
q
Hour button
y
Minute button
r
Display screen
z
Preset indicator
s
Start button
{
Keep-warm indicator
t
Pressure-keeping time
button
|
Keep-pressure
indicator
u
Cooking functions
© 2020 Koninklijke Philips N.V.
All rights reserved.
6608 000 05810
Functions overview
Cooking function Default
pressure-
keeping time
(minute)
Adjustable
pressure-
keeping time
(minute)
Beef ( ) 30 15-59
Chicken ( )
20 18-25
Chop ( )
30 10-30
Fish ( )
4 4-15
Pudding ( ) 14 5-30
Beans ( )
30 20-50
Rice ( )
3 3-20
Vegetable ( )
3 3-15
Potato ( )
15 4-15
Soup ( )
10 5-30
Manual
( )
1 1-59
4 Using the electric pressure
cooker
Before rst use
1 Remove all packaging materials from the appliance.
2 Take out all the accessories from the inner pot.
3 Clean the parts of the electric pressure cooker
thoroughly before using it for the rst time (see
chapter ‘Cleaning and Maintenance’).
Note
• Make sure all parts are completely dry before you
start using the electric pressure cooker.
Preparations before cooking
Before using the electric pressure cooker to cook food,
you need to follow below preparations:
1 Hold the lid handle and turn it anti-clockwise until
the top lid cannot move any more, then lift up the
top lid. (g. 4)
2 Take out the inner pot from the electric pressure
cooker and put the pre-washed food in the inner pot.
(g. 5)
3 Wipe the outside of the inner pot dry and put it back
into the electric pressure cooker. (g. 6)
4 Place the top lid onto the electric pressure cooker
and turn it clockwise. You will hear a “click” sound
when the top lid is properly locked. (g. 7)
5 Turn the pressure control to the sealed position ( ).
(g. 8)
6 Put the plug in the power socket. (g. 9)
Note
• Make sure the sealing ring is properly assembled
around the inside of the top lid.
• Make sure the pressure regulator valve and oating
valve are clean and not blocked.
• Make sure the outside of the inner pot is dry and
clean, and that there is no foreign residue on the
heating element.
• Make sure the inner pot is in proper contact with the
heating element.
Cooking food
Note
• Do not ll the inner pot with less than 1/3 or more
than 2/3 full of food and liquid.
• For food that expands during cooking, do not ll the
inner pot with more than 1/2 full of food and liquid.
• For rice cooking, follow the water level indications
on the inside of the inner pot. You can adjust the
water level for dierent types of rice and your own
preference. Do not exceed the quantities indicated
on the inside of the inner pot.
• Make sure the oater falls down before cooking.
1 Follow the preparation steps in “Preparations before
use”.
2 Press the cooking function button to choose the
cooking mode you need. (g. 10)
» The selected cooking mode indicator ashes.
» The default pressure-keeping time displays on
the screen.
3 If you want to set a dierent pressure-keeping time,
press the pressure-keeping time button ( ). (g. 11)
» The pressure-keeping time ashes on the screen.
4 Press the minute button ( ) to set the pressure-
keeping time you need. (g. 12)
5 Press the start button ( ) and the electric pressure
cooker starts working in the selected mode. (g. 13)
6 When the electric pressure cooker reaches the working
pressure, the keep-pressure indicator lights up.
» The electric pressure cooker enters pressure-
keeping mode.
7 When the pressure-keeping time has elapsed, the
electric pressure cooker automatically switches to
keep-warm mode.
8 Turn the pressure regulator to the steam vent ( )
position. (g .14)
» The electric pressure cooker starts releasing
pressure.
» The oater drops when the pressure is released
suciently.
9 Hold the top lid handle and turn the lid anti-clockwise
until it cannot move any more, then lift it up. (g. 4)
Caution
• When cooking soup or viscous liquid, do not release
pressure by turning the pressure regulator valve
to the steam vent position, otherwise liquid might
spurt from the pressure control valve. Wait until the
pressure is naturally released and the oater has
dropped to open the top lid.
Note
• The pressure-keeping timer will start counting down
when the working pressure is reached.
• After the cooking is nished and the pressure is
released, unplug the electric pressure cooker to turn
o the keep-warm function or when not in use.
www.philips.com/welcome
User manual
wwwwww.philips.com/welcome
Safety leaflet
www.philips.com/welcome
Warranty
7
9
65
q
r
n
o
p
|
{
z
s
t
u
b
a
c
d
e
g
f
h
m
l
i
k
j
y
w
x
v
4
10 11 12
17
13 15
16
19
8
18
14
20
1 2 3
21
Tip
• You can adjust the pressure-keeping time for
dierent types of food according to your preference.
Using the "Manual ( )"
function
You can use the manual function to set the pressure-
keeping time you need.
1 Follow the steps in “Preparations before cooking”.
2 Press the Manual button ( ). (g. 15)
» The pressure-keeping time ashes on the
screen.
3 Press the minute button ( ) to set the pressure-
keeping time you need. (g. 12)
4 Press the start button ( ) and the electric pressure
cooker starts working with the chosen pressure-
keeping time. (g. 13)
Note
• The pressure-keeping time is available from 1 to 59
minutes.
Preset time for delayed cooking
You can preset the delayed cooking time for dierent
cooking functions. The preset timer is available up to 24
hours.
1 Follow the preparation steps in “Using the electric
pressure cooker”.
2 Choose a cooking function you need, and then press
the timer button ( ). (g. 16)
3 Press the hour button ( ) and minute button
( ) to set the preset time. (g. 17)
4 Once the preset time is set, press the start button
( ) to enter preset mode. (g. 13)
5 When the preset time has elapsed, the electric
pressure cooker starts working automatically.
6 When the cooking is nished, the rice cooker
switches to keep-warm mode automatically, and the
keep-warm indicator will be on.
Note
• Do not exceed the volume indicated nor exceed
the maximum water level indicated in the inner pot,
as this may cause the electric pressure cooker to
overow.
Assembling and disassembling the
pressure regulator
Caution
• Do not disassemble the pressure regulator during
cooking. Always unplug the electric pressure cooker
and wait until the pressure has been released
suciently.
To disassemble the pressure regulator:
1 Turn the lower screw anti-clockwise until it becomes
loose. (g. 18)
2 Pull it up and take out the pressure regulator. (g. 19)
To assemble the pressure regulator:
1 Assemble the lower screw back to the regulator, and
then point the regulator to the sealed position and
put it back to the steam valve. (g. 20)
2 Turn the screw clockwise until it is fastened. (g. 21)
4 Specifications
Model Number RI3136
Rated power output 900W
Rated capacity 5.0L
Diameter 22cm
Keep-warm temperature 60-80°C
Note
• Always unplug the appliance if not used for a longer
period.
5 Cleaning and Maintenance
Note
• Unplug the electric pressure cooker before starting
to clean it.
• Wait until the electric pressure cooker has cooled
down suciently before cleaning it.
Interior
Inside of the outer lid and the main body:
• Wipe with wrung out and damp cloth.
• Make sure to remove all the food residues stuck
to the electric pressure cooker.
Heating element:
• Wipe with wrung out and damp cloth.
• Remove food residues with wrung out and damp
cloth or toothpicks.
Sealing ring:
• Soak in warm water and clean with sponge.
