shown in the display. Keep the key

depressed to reach the required value

faster.

It serves to decrease any of the values

shown in the display. Keep the key

depressed to reach the required value

faster.

This key is used to select/display the

vacuuming time, from 0 to 99. The key LED

turns on while the operator selects the

vacuuming time and during the

performance of the vacuuming stage.

This key is meant to select/display the

sealing time, from 0 to 7 seconds. The key

LED turns on while the operator selects the

sealing time and during the sealing

operation.

This is to enable/disable the soft air

function. Soft air injection is fixed and

there exists no possibility of changing it.

The key LED is on when the function is

enabled.

This is a double-function key, depending

on whether the lid is open or closed.

L

ID CLOSED-CYCLE SWITCH

It allows interrupting the cycle and going

over to the next stage. Pressing the key

several times results in activating the air

inlet.

L

ID OPEN-VAC-NORM

If you press the key, when the lid is open,

the machine starts extacting air, producing

the vacuum in external containers. Pressing

the key again restores the normal

operating mode.

In order to set the parameters, it is an

ESSENTIAL REQUIREMENT that the COVER

SHOULD BE OPEN. The parameter setting

procedure is described below, taking a

possible cycle as an example:

1. Press the Vacuum key. The LED of this

key turns on. Then, press the

incrementer key till 20 is displayed,

which corresponds to the selected

vacuuming time.

2. Press the Sealing key. The LED of the

key turns on. Using the Incrementer or

Decrementer key, have value 3.0 being

the duration in seconds of bag sealing,

displayed.

3. Press the Soft Air key. The built-in LED

turns on, indicating that the Soft Air

function is enabled.

4. In order to change any of the entered

values at any time, it is as simple as to

press the relevant function key and to

select the new value with the

Incrementer or Decrementer key.

5. Close the cover immediately after

having selected all the values of the

cycle. The settings are stored

automatically.

On closing the cover, the working cycle

starts automatically. As the cycle is

carried out, the key built-in LEDs

successively turn on, showing the stage of

the cycle in progress. At the end of the

sealing stage, air enters the chamber and

the cover opens automatically.

VAC-NORM FUNCTION

The vacuum packer you have just bought

features a VAC-NORM function that

enables creating a vacuum in trays. To be

able to use this function, you need to

purchase the VAC-NORM kit that includes a

hose and connector to the chamber of the

vacuum packaging machine.

1-Before activating the VAC-NORM

function, fit the connector and hose into

the machine suction inlet.

2-Activate the VAC-NORM function, by

pressing the STOP button with the lid of the

vacuum packer open. Now, the machine

starts extracting air.

3-Place the free end of the hose into the

tray. Now, a vacuum is created inside the

tray. A vacuum gauge shows the amount of

vacuum produced. On reaching the desired

vacuum, remove the hose from the tray.

4-Press the STOP button again or switch

the machine off; this restores the normal

mode of operation.

Warning! It is advisable to disable the VAC-

NORM function when not in use; otherwise

the machine would be extracting air

continuously, which is harmful to the

pump.

BAG CUTTING

The bars including bag cutting threads are

supplied as an optional kit. To install them,

the sealing bar must be replaced by the

new bar provided with the cutting thread

and one of the wires in the sealing

transformer must be changed to the power

indicated on the electric layout:

- V-410 /V-421 /V-426: 15V (20V

depending on the bag type).

- V-641: 15V (short bar), 23V (long bar)

- V-821: 20V (short bar), 30V (long bar)

For the bag cutting operation, it is enough

to programme the suitable sealing time in

the control panel and, once the bag is

sealed, it is separated manually along the

line marked by the cutting thread.

DIRECTIONS FOR USE AND

MAINTENANCE

Very important:

-Never pack products if they are still hot,

since the vapour generated by them

damages the vacuum pump.

-It is important to clean the interior and

edges of the chamber, as well as the

locking joint, every day.

-The outside of the machine must not be

washed under a direct water jet; instead

you can use a wet cloth and an ordinary

detergent. Never clean the cover with

7

ENGLISH

- Key

Decrementer

Sensor controlled vacuum

Sealing

Soft air inlet

Cycle stop - VAC-NORM

Sealing: 3 s.Vacuum: 20 s.
