Manual Lexibook SW100BB Máquina de costura

Manual

54

English

INTRODUCTION

Hours of fun are guaranteed with this Barbie Sewing Machine! Design new outfits for your Barbie

doll and her friends or even your own clothes and accessories! Your sewing machine works

with a pedal and includes a storage drawer and a rule to check the dimensions before sewing.

You can also launch a new collection right away with the sewing kit including scissors, 3 spools,

a piece of fabric and a cushion. Please read carefully the instructions below before using your

sewing machine for the first time.

BEWARE: KEEP OUT OF REACH OF YOUNG CHILDREN.

BATTERY INSTALLATION

Your Barbie sewing machine works with 2 D batteries (not included).

This game must be powered using only the specified batteries.

1. Open the battery compartment cover located under the sewing machine using a

screwdriver.

2. Install the 2 D batteries observing carefully the polarity indicated at the bottom of

the battery compartment, and as per the diagram shown opposite.

3. Close back the battery compartment and tighten the screw.

4. Turn the game on.

Do not use rechargeable batteries. Do not recharge the batteries. Remove the storage

batteries before recharging. Recharge storage batteries under adult supervision. Do not mix

different types of battery and storage battery, or new and old batteries or storage batteries. Insert batteries and storage

batteries according to the polarity. Remove used storage batteries from game. Do not short-circuit the battery or storage

battery terminals. Keep batteries away from fire. If game remains unused for an extended period, remove batteries. Only

batteries of the same or equivalent type as recommended are to be used. When the sound becomes faint or the game

does not respond, think about replacing the batteries.

WARNING: If the unit malfunctions or receives an electrostatic shock, switch the unit off and on again using the ON/OFF

button. If this proves to be ineffective, remove the batteries and/or perform the Reset procedure.

DISCOVER YOUR BARBIE SEWING MACHINE

The different parts on your Barbie sewing machine are:

1. Foot pedal

2. On/off switch

3. Hand wheel

4. Bobbin case

5. Carrying handle

6. Thread guide

7. Take up lever

8. Presser foot lever

9. Bulb

10. Storage compartment

11. Presser foot

12. Needle plate

13. Tension dial

• After placing the spool of thread in the bobbin

compartment, insert the thread through the

thread guide (6) as shown on diagram E. (Make

sure you insert the thread between the two

discs of the tension dial).

• Raise the needle to its highest point by

turning the hand wheel (3) according to the

direction of the arrow, and thread the needle

from left to right.

• Slide the thread under the presser foot (11),

between the forks and to the rear of the

machine.

USING YOUR SEWING MACHINE

HOW TO SEW:

•

Push the On/Off switch (2) to turn the sewing machine on.

•

Lift the presser foot (3) upwards to make straight stitches or downwards to make zigzag stitches.

•

Lift the presser foot (11) using the presser foot lever (8) located behind the sewing machine.

•

Place the piece of fabric under the presser foot (8) and lower the presser foot lever (8).

•

Press the foot pedal to start sewing.

•

Sew a few stitches by turning the hand wheel (3) according to the direction of arrow.

•

Press the foot pedal (1) and start to sew normally.

•

Move the piece of cloth on the sewing area according to the desired location of the stitches.

•

When the line of stitching has been completed, release the foot pedal. Stop sewing before you

reach the edge of the fabric.

LOCKING THE STITCH:

To prevent the stitch from unraveling, you can lock the stitch by following

these instructions:

•

Pull a length of thread through the tension dial (13) to release the tension

on the needle (see diagram C).

•

Lift the presser foot (11) and turn the hand wheel (3) according to the

direction of the arrow to lift the needle out of the fabric.

•

Cut the thread (see diagram D).

•

Remove the fabric by pulling it toward you; the stitch will be locked automatically. (If your machine jams or the

thread is stuck in the lower part of the sewing mechanism, gently turn the hand wheel until the fabric or thread

can be removed from the machine.)

THREADING YOUR SEWING MACHINE:

• When the thread supplied has run out, please replace it with cotton or polyester thread.

• Lower the presser foot (11) using the presser foot lever (8).
