Installation

2

GB

Mobile venting

A vent tube must always be fitted when the dryer is

used in conjunction with Mobile Venting.

The tube must be fitted securely into the front of the

dryer. If possible, it is always best to connect the tube

to a permanent outlet close to the dryer. If permanent

installation is not possible, the dryer will work just as

well with the tube passing through a partly-opened

window.

! Ensure that the end of the tube is not directed toward

the air intake vent at the rear of the dryer.

! The vent tube should not exceed 2.4 metres in length

and should be kept free of any possible accumulation

of fluff, lint and water by shaking it out frequently.

Always ensure that the tube is not squashed.

Permanent venting

In conjunction with the vent tube we recommend using

a Wall/Window Vent Kit, available at a retail location or

the nearest Spare Parts Dealer.

Window mounting

1. The hole in the window should

ideally be made below the vent.

2. The tube should be

kept as short as possible.

Depending on how often you use your dryer, it is

essential that areas A and B are checked periodically

to remove lint or debris.

The vent tube adaptor must be fitted securely thus

preventing any humid air from being emitted back into

the room.

! The tube should be kept clear of the air intake vent

and kinks or ‘U’ bends must be avoided as these will

obstruct the tube or trap condensation.

Open window venting

The end of the tube should be

directed downwards, to prevent

warm moist air from condensing

in the room or in the dryer.

Wall hanging kit

This allows the dryer to be mounted on a wall of

suitable strength to take the weight. Alternatively it

should be used when the dryer is mounted on top of a

work surface to secure the dryer to the wall.

Where to put your dryer

•

●Place your dryer at a distance from gas

ranges, stoves, heaters, or cook tops

because flames can damage the appliance.

• ●If you are going to install

the appliance under a work

counter, be sure to leave a

50mm space between the

top and any other objects

on or above the machine

and a 25mm space

between the sides and

lateral furnishings or walls.

This is to ensure proper air circulation. Make

sure that the back vents are not obstructed.

•

●Make sure you put your dryer in an

environment that is not damp and has

proper air circulation throughout, the dryer

will not operate efficiently in an enclosed

space or cupboard.

! We do not recommend that the dryer is

installed in a cupboard but the dryer must

never be installed behind a lockable door,

a sliding door or a door with a hinge on the

opposite side to that of the dryer door.

! The appliance must be installed with the

rear surface placed against a wall.

Ventilation

The Dryer dries your laundry by drawing in cool, clean and

relatively dry air, heating it, and then distributing it through

the clothes as they are gently tumbled.

For optimum performance, the moist air is then blown out

through a vent tube.

When the dryer is in use, there has to be adequate

ventilation to avoid the back flow of gases into the room

from appliances burning other fuels, including open fires.

! Ensure that the dryer is adequately ventilated and that

the end of the vent tube is not directed towards the air

intake duct.

! The vent tube must always be fitted for optimum

performance.

! Make sure that the vent tube and air

intake vents are not

obstructed or blocked.

! The dryer must not recycle exhaust air.

! Misusing a tumble dryer may create a fire hazard.

! Do not discharge exhaust air into a flue which is used

for exhaust fumes from other appliances that burn gas or

other fuels.

! Do not discharge exhaust air into an extraction system or

any duct with an extractor fan. This will affect the way the

thermal controls operate and can result in a fire hazard.

! Do not allow clothes, towels etc., to hang down the front

of the dryer into the airstream. This obstructs the airflow

and may damage the dryer.

Minimum gap 50mm

Minimum gaps

25mm
