Manual

4

English

6. Do not stop the saw blades by lateral pressure on the

disc.

7. Always keep the saw blades sharp.

8. Ensure that the lower guard moves smoothly and freely.

9. Never use the circular saw with its lower guard fi xed in

the open position.

10. Ensure that the retraction mechanism of the guard

system operates correctly.

11. Never operate the circular saw with the saw blade turned

upward or to the side.

12. Ensure that the material is free of foreign matters such as

nails.

13. For model C6SS, the saw blades range should be from

160 mm to 165 mm.

For model C7SS, the saw blades range should be from

185 mm to 190 mm.

14. Disconnect the plug from the receptacle before carrying

out any adjustment, servicing or maintenance.

15. Ensure that the power source to be utilized conforms

to the power requirements specifi ed on the product

nameplate.

16. Ensure that the power switch is in the OFF position.

If the plug is connected to a receptacle while the power

switch is in the ON position, the power tool will start

operating immediately, which could cause a serious

accident.

17. When the work area is removed from the power source,

use an extension cord of suffi cient thickness and rated

capacity. The extension cord should be kept as short as

practicable.

18. Since the saw blade will extend beyond the lower surface

of the lumber, place the lumber on a workbench when

cutting. If a square block is utilized as a workbench,

select level ground to ensure it is properly stabilized. An

unstable workbench will result in hazardous operation.

(Fig.1)

To avoid possible accident, always ensure that the

portion of lumber remaining after cutting is securely

anchored or held in position.

19. Should lever (A) remain loosened, it will create a very

hazardous situation. Always thoroughly clamp it. (Fig.2)

20. It is very hazardous to allow wing bolt to remain loosened.

Always thoroughly clamp it. (Fig.3)

21. Prior to cutting operation, make sure the material you

are going to cut. If the material to be cut is expected to

generate harmful / toxic dusts, make sure the dust bag

or appropriate dust extraction system is connected with

dust outlet tightly.

Wear the dust mask additionally, if available.

○ Before starting to saw, confi rm that the saw blade has

attained full-speed revolution.

○ Should the saw blade stop or make an abnormal

noise while operating, promptly turn OFF the switch.

○ Always take care in preventing the power cord from

coming near to the revolving saw blade.

○ Using the circular saw with the saw blade facing

upwards or sideways is very hazardous. Such

uncommon applications should be avoided.

○ When cutting materials, always wear protective

glasses.

○ When fi nished with a job, pull out the plug from the

receptacle.

22. After having attached the saw blade, reconfi rm that the

lock lever is fi rmly secured in the prescribed position.

23. Check that there are no nicks or scratches in the cord.

24. Check the exterior and ensure that there is no damage.

25. Use a saw blade with a displayed rotational speed equal

to or higher than the rotational speed of the tool.

26. Use a saw blade that suits each diff erent cutting material.

SYMBOLS

WARNING

The following show symbols used for the machine.

Be sure that you understand their meaning before

use.

C6SS / C7SS : Circular Saw

To reduce the risk of injury, user must read

instruction manual.

Always wear eye protection.

Always wear hearing protection.

Only for EU countries

Do not dispose of electric tools together with

household waste material!

In observance of European Directive 2012/19/

EU on waste electrical and electronic equipment

and its implementation in accordance with

national law, electric tools that have reached

the end of their life must be collected separately

and returned to an environmentally compatible

recycling facility.

V

Rated voltage

Cutting depth

P

Power Input

n

0

No-Load speed

kg

Weight (without cord)*

Switching ON

Switching OFF

Disconnect mains plug from electrical outlet

Class II tool

* According to EPTA-Procedure 01/2014

STANDARD ACCESSORIES

In addition to the main unit (1), the package contains

the accessories listed in the below.

○ Saw Blade (mounted on tool) ......................................1

Dia. 165 mm ................................ C6SS

Dia. 190 mm ................................ C7SS

○ Hex. Bar wrench .........................................................1

○ Dust collector .............................................................1

Standard accessories are subject to change without notice.

APPLICATIONS

Cutting various types of wood.

)(

0000Book̲C6SS.indb40000Book̲C6SS.indb4 2019/02/1216:08:362019/02/1216:08:36
