4 Operation

Operation manual

5

ATXF25~35A5V1B

Daikin room air conditioner

3P520336-8D – 2019.02

Feature Tasks

Airflow rate

To adjust the amount of air blown into

the room.

To run more quietly.

Advanced features

Econo

To use the system when you are also

using other power-consuming

appliances.

To save energy.

Comfort

To provide a comfortable airflow that

does NOT come in direct contact with

people.

Powerful

To cool down or heat up the room

quickly.

ON timer + OFF

timer

To automatically turn ON or OFF the

system.

4.3 Operation mode and temperature

setpoint

When. Adjust the system operation mode and set the temperature

when you want to:

▪ Heat up or cool down a room

▪ Blow air in a room without heating or cooling

▪ Decrease the humidity in a room

What. The system operates differently, depending on the user

selection.

Setting Description

Automatic

The system cools down or heats up a

room to the temperature setpoint. It

automatically switches between cooling

and heating if necessary.

Drying

The system decreases the humidity in a

room.

Heating

The system heats up a room to the

temperature setpoint.

Cooling

The system cools down a room to the

temperature setpoint.

Fan

The system only controls the airflow

(airflow rate and airflow direction).

The system does NOT control the

temperature.

Additional info:

▪ Outside temperature. The system's cooling or heating effect

decreases when the outside temperature is too high or too low.

▪ Defrost operation. During heating operation, frost might occur on

the outdoor unit and decrease the heating capacity. In that case,

the system automatically switches to defrosting operation to

remove the frost. During defrosting operation, hot air is NOT

blown from the indoor unit.

4.3.1 To start/stop operation mode and to set

the temperature

: Unit is operating.

: Operation mode = Automatic

: Operation mode = Drying

: Operation mode = Heating

: Operation mode = Cooling

: Operation mode = Fan only

: Shows the set temperature.

1 Press one or more times to select the operation mode.

Result: The mode will be set in the following sequence:

2 Press to start operation.

Result: is displayed on the LCD.

Result: The operation lamp lights up.

3 Press or on the button one or more times to lower or

raise the temperature.

Note: When using drying or fan only mode, you cannot adjust the

temperature.

4 Press to stop operation.

Result: disappears from the LCD.

Result: The operation lamp goes off.

4.3.2 Airflow rate

1 Press to choose:

5 airflow rate levels, from " " to " "

Automatic airflow rate operation

Indoor unit quiet operation. When the airflow rate is

set to " ", the noise from the unit will be reduced.

INFORMATION

▪ If the unit reaches the temperature setpoint in cooling

or heating mode, the fan will stop operating.

▪ When using drying operation mode, you CANNOT

adjust the airflow rate setting.

To adjust the airflow rate

1 Press to change the airflow setting as follows:
