Operation manual

2

ATXF25~35A5V1B

Daikin room air conditioner

3P520336-8D – 2019.02

Table of contents

1 About the documentation 2

1.1 About this document.................................................................. 2

2 About the system 2

2.1 Indoor unit ................................................................................. 2

2.2 About the user interface ............................................................ 3

2.2.1 Components: User interface ....................................... 3

2.2.2 Status: User interface LCD ......................................... 3

2.2.3 To operate the user interface...................................... 4

3 Before operation 4

3.1 To mount the user interface holder ........................................... 4

3.2 To insert the batteries................................................................ 4

3.3 To turn on the power supply...................................................... 4

4 Operation 4

4.1 Operation range ........................................................................ 4

4.2 When to use which feature........................................................ 4

4.3 Operation mode and temperature setpoint................................ 5

4.3.1 To start/stop operation mode and to set the

temperature................................................................. 5

4.3.2 Airflow rate.................................................................. 5

4.3.3 Airflow direction........................................................... 6

4.3.4 Comfort airflow operation............................................ 6

4.3.5 Powerful operation...................................................... 6

4.3.6 Econo operation.......................................................... 7

4.3.7 OFF/ON timer operation ............................................. 7

5 Energy saving and optimum operation 7

6 Maintenance and service 7

6.1 Overview: Maintenance and service ......................................... 7

6.2 To clean the indoor unit and user interface ............................... 8

6.3 To clean the front panel............................................................. 8

6.4 About the air filters .................................................................... 8

6.5 To clean the air filters ................................................................ 8

6.6 To take following items into account before a long idle period.. 9

7 Troubleshooting 9

7.1 Symptoms that are NOT system malfunctions .......................... 9

7.1.1 Symptom: A sound like water flowing is heard ........... 9

7.1.2 Symptom: A blowing sound is heard........................... 9

7.1.3 Symptom: A ticking sound is heard............................. 9

7.1.4 Symptom: A whistling sound is heard......................... 9

7.1.5 Symptom: A clicking sound during operation or idle

time is heard ............................................................... 9

7.1.6 Symptom: A clapping sound is heard ......................... 9

7.1.7 Symptom: The units can give off odours..................... 10

7.1.8 Symptom: The outdoor fan rotates while the air

conditioner is not in operation ..................................... 10

7.2 Solving problems based on error codes.................................... 10

8 Disposal 10

1 About the documentation

1.1 About this document

Thank you for purchasing this product. Please:

▪ Keep the documentation for future reference.

Target audience

Endusers

INFORMATION

This appliance is intended to be used by expert or trained

users in shops, in light industry, and on farms, or for

commercial and household use by lay persons.

Documentation set

This document is part of a documentation set. The complete set

consists of:

▪ General safety precautions:

▪ Safety instructions that you must read before operating your

system

▪ Format: Paper (in the box of the indoor unit)

▪ Operation manual:

▪ Quick guide for basic usage

▪ Format: Paper (in the box of the indoor unit)

▪ User reference guide:

▪ Detailed step-by-step instructions and background information

for basic and advanced usage

▪ Format: Digital files on http://www.daikineurope.com/support-

and-manuals/product-information/

Latest revisions of the supplied documentation may be available on

the regional Daikin website or via your installer.

The original documentation is written in English. All other languages

are translations.

2 About the system

WARNING: FLAMMABLE MATERIAL

The refrigerant inside this unit is mildly flammable.

NOTICE

Do NOT use the system for other purposes. In order to

avoid any quality deterioration, do NOT use the unit for

cooling precision instruments, food, plants, animals, or

works of art.

2.1 Indoor unit

CAUTION

Do NOT insert fingers, rods or other objects into the air

inlet or outlet. When the fan is rotating at high speed, it will

cause injury.

INFORMATION

The sound pressure level is less than 70dBA.

WARNING

▪ Do NOT modify, disassemble, remove, reinstall or

repair the unit yourself as incorrect dismantling or

installation may cause an electrical shock or fire.

Contact your dealer.

▪ In case of accidental refrigerant leaks, make sure there

are no naked flames. The refrigerant itself is entirely

safe, non-toxic and mildly flammable, but it will

generate toxic gas when it accidentally leaks into a

room where combustible air from fan heaters, gas

cookers, etc. is present. Always have qualified service

personnel confirm that the point of leakage has been

repaired or corrected before resuming operation.
