PLEASE READ AND SAVE THESE

IMPORTANT INSTRUCTIONS

When using electrical appliances, basic safety

precautions should always be taken including

the following:

1. Before connecting the heater, check that the

voltage indicated on the rating plate

corresponds to the main voltage in your

home/office.

2. WARNING: In order to avoid overheating,

do not cover the heater ( ) Reference to

product.

3. DO NOT position the heater directly under a

power socket.

4. DO NOT use this heater in the immediate

surroundings of a bath, a shower or a

swimming pool.

5. If the supply cord or plug is damaged, it must

be replaced by the manufacturer or its service

agent or similarly qualified person in order to

avoid hazard. The heater contains no user

serviceable parts. Should the product suffer

damage or breakdown, it must be returned to

the manufacturer or their service agent.

6. Under the environment with electrical fast

transient, the product may malfunction.

7. DO NOT use this heater with a

programmer, timer or any other device

that switches the heater on automatically,

since a fire risk exists if the heater is

covered or positioned incorrectly.

8. Only touch the heater with dry hands.

9. DO NOT use this heater outdoors.

10. DO NOT position where it can be touched by

children, especially the very young.

11. Allow a safe area around the heater away

from furniture or other objects; at least 50

cm from the top and sides and 200 cm at

the front. The heater is to be placed at least

3m from water source.

12. DO NOT use this heater when it is lying on

its side.

13. DO NOT use the heater in rooms with

explosive gas (e.g. petrol) or while using,

oxygen, inflammable glue or solvent (e.g.

when gluing or varnishing parquet floors,

PVC etc.)

14. DO NOT insert any objects into the heater.

15. Keep the mains cord at a safe distance from

the main body of the heater.

16. If overheating should occur, the built-in

overheating safety device will switch off

the heater.

17. DO NOT place the cord under a rug.

18. The heater cannot be used adjacent to

curtains or combustible material. Curtains or

combustible material may be burned if the

heater was installed incorrectly.

19. This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or

lack of experience and knowledge, unless

they have been given supervision or

instruction concerning use of the appliance

by a person responsible for their safety.

Children should be supervised to ensure that

they do not play with the appliance.

20. This heater is filled with a precise quantity of

special oil. Repairs requiring opening of the

oil container are only to be made by the

manufacturer or his service agent who

should be contacted if there is an oil leak;

21 when scrapping the heater, follow the

regulations concerning the disposal of oil.

DESCRIPTIONS (See Fig. 1, 2 & 3)

A. Heated Fins

B. Vents

C. Handle

D. Front Panel

E. Cord Storage

F. Power Cord

G. Front Stand

H. Control Knob

I. Power Light

J. Thermostat Knob

K. Q Shape Screw

L. Casters

M.Foot Plate

N. Wing Nut

O. U-bolt

Technical Specifications

BOH1501/W

Wattage: 1500W

BOH2001/W

Wattage: 2000W

ASSEMBLY INSTRUCTIONS (See Fig. 3)

Please make sure the heater has not been

plugged into any electricity outlet.

Carefully remove heater from box. Some

acessories are packed internally. Please make

sure you have all of the following acessories

prior to throwing away packaging.

1 Foot Plate with 2 casters (M&L), 1 Front Stand (G),

and 1 Q shape Screw (K) and 1 Wing Nut (N).

Note: This unit is for FLOOR USE ONLY.

1. Turn the heater upside down and you will see

one U-bolt (O) with wing nut over the last joint

of the heater.

ENGLISH

2. Unscrew the wing nut (N) from the U-bolt (O).

3. Place one hole of the foot plate (M) to the L

shape of the U-bolt (O) and the other hole of

the foot plate into the other end of the U-bolt,

then screw on the wing nut (N).

4. Place the front stand (G) on the bottom of the

radiators front panel, and secure it with the Q

shape screw (K). This front stand (G) is not

meant to be removed once it is attached to

the bottom of the unit.

5. After installation of the front stand (G) and foot

plate (M) with casters (L) turn the heater the

right way up: the heater is now ready for use.

OPERATING INSTRUCTIONS

(See Fig. 1&2)

1. Set the unit to the OFF (O) position.

2. Plug in heater. The Power Light (I) will

illuminate and remain lit until the heater

is unplugged.

3. Set the Thermostat Knob (J) all the way to

the right.

4. Turn the Control Knob (H) to desired level of heat.

NOTE: When the heater is in use, it is

normal that the heater cycles ON and OFF,

this is to maintain your desired temperature.

After using the heater, turn the Control Knob (H)

to “0” position, turn the Thermostat Knob (J) to

lowest temperature position and unplug the

heater from the socket.

Turn the Control Knob to desired heat setting.

BOH1501/W: 1 -600W, 2 -900W, 3-1500W

BOH2001/W: 1 -800W, 2 -1200W, 3 -2000W

SETTING THE THERMOSTAT

1. Set the Thermostat control all the way to max.

2. When the desired temperature/comfort level is

reached, turn the thermostat control

anti-clockwise to lower position or until the

heater stops operating.

3. The control will now automatically maintain

the pre-set temperature level by turning the

heater ON and OFF.

NOTE: The Power light will remain lit during

operation.

NOTE: It is normal for the heater to cycle ON

and OFF as it maintains the preset

temperature.

ANTI-FROST GUARD INSTRUCTION

If you plug in the heater, it will start working at the

lowest temperature setting (When thermostat

control is in the lowest temperature position, the

temperature will be maintained at 5° C, thus the

heater will be in the off status unless the room

temperature is lower than 5° C. If the room

temperature is lower than 5° C, the heater will

automatically start working and will keep turning

on & off all the time, maintaining its ambient

temperature of 5° C.

NOTE: Unit must be unplugged for it to be

fully off

TIP OVER PROTECTION

When the unit is accidentally knocked over, or

tilts on one side at more than a 45° angle; it

will instantly shut off. To reset, simply place the

heater in an upright position.

STORAGE TIPS

If the heater is not required for long periods, for

example during the summer, it should be stored

at room temperature; in a dry place and

preferably covered to prevent the accumulation

of dust and dirt.

FITTING A REPLACEMENT PLUG FOR

U.K. AND IRELAND ONLY.

If the plug is not suitable for the socket outlets in

your home, it can be removed and replaced by a

plug of the correct type. For correct type and

correct installation please refer to "Installation of

a plug" below.

INSTALLATION OF A PLUG – Applicable to

U.K. and Ireland.

NOTE: If you are in any doubt about wiring

and the installation of the plug. Please

contact a qualified electrician.

NOTE: If a 13A 3-pin plug is fitted, it must be

an ASTA approved plug, conforming to the

BS1363 standard. Replacement 13 amp fuse

must also be BSI or ASTA approved.

The wires in this mains lead are coloured as such:

GREEN & YELLOW - Earth

BROWN - Live

BLUE - Neutral

Please note that the colour of these mains wires

may not correspond with the colour markings

that identify the terminals in your plug.

BOH1501-I_IB_REV.qxd:BPH1515I06MLM1.qxd 3/19/09 11:55 AM Page 2
